Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
Internal Part Number | EIS-MCC255-14IO1 | |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
Production Status (Lifecycle) | In Production | |
Condition | New & Unused, Original Sealed | |
Other Related Documents | SCR Module Selection Guide | |
Standard Package | 3 | |
Category | Discrete Semiconductor Products | |
Family | SCRs - Modules | |
Series | - | |
Packaging | Bulk | |
Structure | Series Connection - All SCRs | |
Number of SCRs, Diodes | 2 SCRs | |
Voltage - Off State | 1400V | |
Current - Gate Trigger (Igt) (Max) | 150mA | |
Current - On State (It (AV)) (Max) | 250A | |
Current - On State (It (RMS)) (Max) | 450A | |
Current - Non Rep. Surge 50, 60Hz (Itsm) | 9000A, 9600A | |
Current - Hold (Ih) (Max) | 150mA | |
Mounting Type | Chassis Mount | |
Package / Case | Y1-CU | |
Weight | 0.001 KG | |
Application | Email for details | |
Alternative Part (Replacement) | MCC255-14IO1 | |
Related Links | MCC255, MCC255-14IO1 Datasheet, IXYS Corporation Distributor |
