NXP Semiconductors/Freescale Semiconductor, Inc. MCF52268VN80
- Mfg. Part Number
- MCF52268VN80
- Manufacturer
- NXP Semiconductors/Freescale Semiconductor, Inc.
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 32BIT 512KB FLASH 144BGA
- Datasheet Download
- MCF52268VN80.pdf
Availability of MCF52268VN80
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MCF52268VN80, we specialize in NXP Semiconductors/Freescale Semiconductor, Inc. all series electronic components. MCF52268VN80 can be shipped within 24 hours after order. If you have any demands for MCF52268VN80, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MCF52268VN80 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MCF52268VN80
| Internal Part Number | EIS-MCF52268VN80 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Standard Package | 160 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | - | |
| Packaging | Tray | |
| Core Processor | Coldfire V2 | |
| Core Size | 32-Bit | |
| Speed | 80MHz | |
| Connectivity | CAN, EBI/EMI, Ethernet, I²C, QSPI, UART/USART, USB OTG | |
| Peripherals | DMA, LVD, POR, PWM, WDT | |
| Number of I/O | 96 | |
| Program Memory Size | 512KB (512K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 64K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 3 V ~ 3.6 V | |
| Data Converters | A/D 8x12b | |
| Oscillator Type | Internal | |
| Operating Temperature | 0°C ~ 70°C | |
| Package / Case | 144-LBGA | |
| Supplier Device Package | 144-MAPBGA (13x13) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MCF52268VN80 | |
| Related Links | MCF522, MCF52268VN80 Datasheet, NXP Semiconductors/Freescale Semiconductor, Inc. Distributor | |
