Varitronix International Ltd. MDLS-16265-SS-LV-G-LED-04-G-14
- Mfg. Part Number
- MDLS-16265-SS-LV-G-LED-04-G-14
- Manufacturer
- Varitronix International Ltd.
- Product Category
- Display Modules - LCD, OLED Character and Numeric
- Brief Description
- LCD MODULE 16X2 STD W/BACKLIGHT
- Datasheet Download
- MDLS-16265-SS-LV-G-LED-04-G-14.pdf
Availability of MDLS-16265-SS-LV-G-LED-04-G-14
Available Quantity
4000 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MDLS-16265-SS-LV-G-LED-04-G-14, we specialize in Varitronix International Ltd. all series electronic components. MDLS-16265-SS-LV-G-LED-04-G-14 can be shipped within 24 hours after order. If you have any demands for MDLS-16265-SS-LV-G-LED-04-G-14, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MDLS-16265-SS-LV-G-LED-04-G-14 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MDLS-16265-SS-LV-G-LED-04-G-14
| Internal Part Number | EIS-MDLS-16265-SS-LV-G-LED-04-G-14 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Standard Character Module Specs. | |
| Standard Package | 100 | |
| Category | Optoelectronics | |
| Family | Display Modules - LCD, OLED Character and Numeric | |
| Series | MDL(S)-16265 | |
| Number of Characters | 32 | |
| Display Format | 16 x 2 | |
| Character Format | 5 x 8 Dots | |
| Display Type | STN - Super-Twisted Nematic | |
| Display Mode | Transflective | |
| Character Size | 5.55mm H x 2.95mm W | |
| Outline L x W x H | 84.00mm x 44.00mm x 9.80mm | |
| Viewing Area | 61.00mm L x 15.80mm W | |
| Backlight | LED - Green | |
| Voltage - Supply | 5V | |
| Dot Size | 0.55mm W x 0.65mm H | |
| Interface | Parallel | |
| Operating Temperature | -5°C ~ 50°C | |
| Text Color | - | |
| Background Color | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MDLS-16265-SS-LV-G-LED-04-G-14 | |
| Related Links | MDLS-16265-SS-L, MDLS-16265-SS-LV-G-LED-04-G-14 Datasheet, Varitronix International Ltd. Distributor | |
