Microchip Technology MIC2005-0.8YM6-TR
- Mfg. Part Number
- MIC2005-0.8YM6-TR
- Manufacturer
- Microchip Technology
- Product Category
- PMIC - Power Distribution Switches, Load Drivers
- Brief Description
- IC DISTRIBUTION SW 0.8A SOT23-6
- Datasheet Download
- MIC2005-0.8YM6-TR.pdf
Availability of MIC2005-0.8YM6-TR
Available Quantity
8020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.61000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MIC2005-0.8YM6-TR, we specialize in Microchip Technology all series electronic components. MIC2005-0.8YM6-TR can be shipped within 24 hours after order. If you have any demands for MIC2005-0.8YM6-TR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MIC2005-0.8YM6-TR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MIC2005-0.8YM6-TR
| Internal Part Number | EIS-MIC2005-0.8YM6-TR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | Wafer Size Update 02/Sep/2015 | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Switch Type | General Purpose | |
| Number of Outputs | 1 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | High Side | |
| Output Type | P-Channel | |
| Interface | On/Off | |
| Voltage - Load | 2.5 V ~ 5.5 V | |
| Voltage - Supply (Vcc/Vdd) | Not Required | |
| Current - Output (Max) | 800mA | |
| Rds On (Typ) | 70 mOhm | |
| Input Type | Non-Inverting | |
| Features | Slew Rate Controlled | |
| Fault Protection | Current Limiting (Fixed), Over Temperature | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Package / Case | SOT-23-6 | |
| Supplier Device Package | SOT-23-6 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MIC2005-0.8YM6-TR | |
| Related Links | MIC2005-, MIC2005-0.8YM6-TR Datasheet, Microchip Technology Distributor | |
MIC2005-0.8YM6-TR Details Description
