Microchip Technology MIC2292C-15YML-TR
- Mfg. Part Number
- MIC2292C-15YML-TR
- Manufacturer
- Microchip Technology
- Product Category
- PMIC - LED Drivers
- Brief Description
- IC LED Driver DC DC Regulator Analog, PWM Dimming 750mA (Switch) Backlight 8-MLF (2x2)
- Datasheet Download
- MIC2292C-15YML-TR.pdf
Availability of MIC2292C-15YML-TR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.84000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MIC2292C-15YML-TR, we specialize in Microchip Technology all series electronic components. MIC2292C-15YML-TR can be shipped within 24 hours after order. If you have any demands for MIC2292C-15YML-TR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MIC2292C-15YML-TR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MIC2292C-15YML-TR
| Internal Part Number | EIS-MIC2292C-15YML-TR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| PCN Assembly/Origin | Wafer Size Update 02/Sep/2015 | |
| Standard Package | 5,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - LED Drivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | DC DC Regulator | |
| Topology | Step-Up (Boost) | |
| Internal Switch(s) | Yes | |
| Number of Outputs | 1 | |
| Voltage - Supply (Min) | 2.5V | |
| Voltage - Supply (Max) | 10V | |
| Voltage - Output | - | |
| Current - Output / Channel | 750mA (Switch) | |
| Frequency | 1.6MHz | |
| Dimming | Analog, PWM | |
| Applications | Backlight | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-VFDFN Exposed Pad, 8-MLF® | |
| Supplier Device Package | 8-MLF® (2x2) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MIC2292C-15YML-TR | |
| Related Links | MIC2292C, MIC2292C-15YML-TR Datasheet, Microchip Technology Distributor | |
MIC2292C-15YML-TR Details Description
