Apem Inc. MJTP1138BLTUBE
- Mfg. Part Number
- MJTP1138BLTUBE
- Manufacturer
- Apem Inc.
- Product Category
- Tactile Switches
- Brief Description
- SWITCH TACTILE SPST-NO 0.05A 12V
- Datasheet Download
- MJTP1138BLTUBE.pdf
Availability of MJTP1138BLTUBE
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.66444
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MJTP1138BLTUBE, we specialize in Apem Inc. all series electronic components. MJTP1138BLTUBE can be shipped within 24 hours after order. If you have any demands for MJTP1138BLTUBE, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MJTP1138BLTUBE Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MJTP1138BLTUBE
| Internal Part Number | EIS-MJTP1138BLTUBE | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 90 | |
| Category | Switches | |
| Family | Tactile Switches | |
| Series | MJTP | |
| Packaging | Tube | |
| Circuit | SPST-NO | |
| Switch Function | Off-Mom | |
| Contact Rating @ Voltage | 0.05A @ 12VDC | |
| Actuator Type | Standard | |
| Mounting Type | Surface Mount | |
| Actuator Height off PCB, from Pins | 9.50mm | |
| Actuator Orientation | Top Actuated | |
| Termination Style | Gull Wing | |
| Outline | 6.00mm x 6.00mm | |
| Illumination | Non-Illuminated | |
| Illumination Voltage (Nominal) | - | |
| Illumination Type, Color | - | |
| Operating Force | 160gf | |
| Ingress Protection | - | |
| Features | Tactile Feedback | |
| Actuator Material | Polyamide (PA46), Nylon 4/6 | |
| Switch Travel | 0.25mm | |
| Mechanical Life | 1,000,000 Cycles | |
| Operating Temperature | -20°C ~ 70°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MJTP1138BLTUBE | |
| Related Links | MJTP113, MJTP1138BLTUBE Datasheet, Apem Inc. Distributor | |
MJTP1138BLTUBE Details Description
