Omron Automation & Safety MK2P-I-AP3 AC24
- Mfg. Part Number
- MK2P-I-AP3 AC24
- Manufacturer
- Omron Automation & Safety
- Product Category
- Power Relays, Over 2 Amps
- Brief Description
- RELAY GEN PURPOSE DPDT 10A 24V
- Datasheet Download
- MK2P-I-AP3 AC24.pdf
Availability of MK2P-I-AP3 AC24
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MK2P-I-AP3 AC24, we specialize in Omron Automation & Safety all series electronic components. MK2P-I-AP3 AC24 can be shipped within 24 hours after order. If you have any demands for MK2P-I-AP3 AC24, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MK2P-I-AP3 AC24 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MK2P-I-AP3 AC24
| Internal Part Number | EIS-MK2P-I-AP3 AC24 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Relays | |
| Family | Power Relays, Over 2 Amps | |
| Series | MK | |
| Packaging | Bulk | |
| Relay Type | General Purpose | |
| Coil Type | Non Latching | |
| Coil Current | 88mA | |
| Coil Voltage | 24VAC | |
| Contact Form | DPDT (2 Form C) | |
| Contact Rating (Current) | 10A | |
| Switching Voltage | 250VAC, 250VDC - Max | |
| Turn On Voltage (Max) | 19.2 VAC | |
| Turn Off Voltage (Min) | 7.2 VAC | |
| Operate Time | 20ms | |
| Release Time | 20ms | |
| Features | Mechanical Indicator | |
| Mounting Type | Socketable | |
| Termination Style | Plug In, 8 Pin (Octal) | |
| Contact Material | Silver (Ag) | |
| Coil Power | 2.3 VA | |
| Coil Resistance | 68 Ohms | |
| Operating Temperature | -10°C ~ 40°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MK2P-I-AP3 AC24 | |
| Related Links | MK2P-I-, MK2P-I-AP3 AC24 Datasheet, Omron Automation & Safety Distributor | |
MK2P-I-AP3 AC24 Details Description
