NKK Switches MLW3018-06-RB-2A
- Mfg. Part Number
- MLW3018-06-RB-2A
- Manufacturer
- NKK Switches
- Product Category
- Rocker Switches
- Brief Description
- SWITCH ROCKER SPDT 5A 125V
- Datasheet Download
- MLW3018-06-RB-2A.pdf
Availability of MLW3018-06-RB-2A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 13.60000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MLW3018-06-RB-2A, we specialize in NKK Switches all series electronic components. MLW3018-06-RB-2A can be shipped within 24 hours after order. If you have any demands for MLW3018-06-RB-2A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MLW3018-06-RB-2A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MLW3018-06-RB-2A
| Internal Part Number | EIS-MLW3018-06-RB-2A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | MLW Series, Cert of Compliance | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Rocker Switches | |
| Series | MLW | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | Mom-Off-Mom | |
| Current Rating | 5A (AC), 3A (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Concave (Curved) - Illuminated | |
| Color - Actuator/Cap | White | |
| Actuator Marking | No Marking | |
| Illumination Type, Color | Incandescent, White | |
| Illumination Voltage (Nominal) | 6 VAC | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination Style | Solder Lug | |
| Ingress Protection | - | |
| Features | Epoxy Sealed Terminals | |
| Panel Cutout Dimensions | Square - 19.20mm² | |
| Operating Temperature | -10°C ~ 50°C | |
| Mechanical Life | 30,000 Cycles | |
| Electrical Life | 10,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MLW3018-06-RB-2A | |
| Related Links | MLW3018-, MLW3018-06-RB-2A Datasheet, NKK Switches Distributor | |
