Fairchild Semiconductor MM3Z56VC
- Mfg. Part Number
- MM3Z56VC
- Manufacturer
- Fairchild Semiconductor
- Product Category
- Diodes - Zener - Single
- Brief Description
- DIODE ZENER 56V 200MW SOD323F
- Datasheet Download
- MM3Z56VC.pdf
Availability of MM3Z56VC
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.01676
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MM3Z56VC, we specialize in Fairchild Semiconductor all series electronic components. MM3Z56VC can be shipped within 24 hours after order. If you have any demands for MM3Z56VC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MM3Z56VC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MM3Z56VC
| Internal Part Number | EIS-MM3Z56VC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | SOD323F Material 16/Apr/2013 | |
| Standard Package | 3,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Voltage - Zener (Nom) (Vz) | 56V | |
| Tolerance | ±5% | |
| Power - Max | 200mW | |
| Impedance (Max) (Zzt) | 188 Ohm | |
| Current - Reverse Leakage @ Vr | 45nA @ 39.2V | |
| Voltage - Forward (Vf) (Max) @ If | 1V @ 10mA | |
| Operating Temperature | -65°C ~ 150°C | |
| Mounting Type | Surface Mount | |
| Package / Case | SC-90, SOD-323F | |
| Supplier Device Package | SOD-323F | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MM3Z56VC | |
| Related Links | MM3Z, MM3Z56VC Datasheet, Fairchild Semiconductor Distributor | |
MM3Z56VC Details Description
