ON Semiconductor MMBTA06LT3G
- Mfg. Part Number
- MMBTA06LT3G
- Manufacturer
- ON Semiconductor
- Product Category
- Transistors (BJT) - Single
- Brief Description
- TRANS NPN 80V 0.5A SOT-23
- Datasheet Download
- MMBTA06LT3G.pdf
Availability of MMBTA06LT3G
Available Quantity
25020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.01702
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MMBTA06LT3G, we specialize in ON Semiconductor all series electronic components. MMBTA06LT3G can be shipped within 24 hours after order. If you have any demands for MMBTA06LT3G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MMBTA06LT3G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MMBTA06LT3G
| Internal Part Number | EIS-MMBTA06LT3G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Gold to Copper Wire 08/May/2007 Glue Mount Process 11/July/2008 Copper Wire Update 10/Sep/2015 | |
| PCN Assembly/Origin | Wafer Source Addition 26/Nov/2014 | |
| Standard Package | 10,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors (BJT) - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Transistor Type | NPN | |
| Current - Collector (Ic) (Max) | 500mA | |
| Voltage - Collector Emitter Breakdown (Max) | 80V | |
| Vce Saturation (Max) @ Ib, Ic | 250mV @ 10mA, 100mA | |
| Current - Collector Cutoff (Max) | 100nA | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 100mA, 1V | |
| Power - Max | 225mW | |
| Frequency - Transition | 100MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | |
| Supplier Device Package | SOT-23-3 (TO-236) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MMBTA06LT3G | |
| Related Links | MMBTA, MMBTA06LT3G Datasheet, ON Semiconductor Distributor | |
MMBTA06LT3G Details Description
