NXP Semiconductors/Freescale Semiconductor, Inc. MPC8543VJANGD
- Mfg. Part Number
- MPC8543VJANGD
- Manufacturer
- NXP Semiconductors/Freescale Semiconductor, Inc.
- Product Category
- Embedded - Microprocessors
- Brief Description
- IC MPU MPC85XX 800MHZ 783FCBGA
- Datasheet Download
- MPC8543VJANGD.pdf
Availability of MPC8543VJANGD
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 108.16778
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MPC8543VJANGD, we specialize in NXP Semiconductors/Freescale Semiconductor, Inc. all series electronic components. MPC8543VJANGD can be shipped within 24 hours after order. If you have any demands for MPC8543VJANGD, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MPC8543VJANGD Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MPC8543VJANGD
| Internal Part Number | EIS-MPC8543VJANGD | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Errata Update 30/Sep/2014 | |
| Standard Package | 36 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microprocessors | |
| Series | MPC85xx | |
| Packaging | Tray | |
| Core Processor | PowerPC e500 | |
| Number of Cores/Bus Width | 1 Core, 32-Bit | |
| Speed | 800MHz | |
| Co-Processors/DSP | Signal Processing; SPE | |
| RAM Controllers | DDR, DDR2, SDRAM | |
| Graphics Acceleration | No | |
| Display & Interface Controllers | - | |
| Ethernet | 10/100/1000 Mbps (4) | |
| SATA | - | |
| USB | - | |
| Voltage - I/O | 1.8V, 2.5V, 3.3V | |
| Operating Temperature | 0°C ~ 105°C | |
| Security Features | - | |
| Package / Case | 783-BBGA, FCBGA | |
| Supplier Device Package | 783-FCPBGA (29x29) | |
| Additional Interfaces | DUART, I²C, PCI, RapidIO | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MPC8543VJANGD | |
| Related Links | MPC854, MPC8543VJANGD Datasheet, NXP Semiconductors/Freescale Semiconductor, Inc. Distributor | |
MPC8543VJANGD Details Description
