KEMET MPLC0730L2R2

MPLC0730L2R2 picture photo
Mfg. Part Number
MPLC0730L2R2
Manufacturer
Product Category
Fixed Inductors
Brief Description
FIXED IND 2.2UH 7.3A 19 MOHM SMD
Datasheet Download
MPLC0730L2R2.pdf
Availability of MPLC0730L2R2

Available Quantity

7020 Pieces

Can ship today


Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks

Marketing Price
$ 0.31920
Our Price
Quote by Email

QUANTITY



EIS Components is the stocking Distributor of MPLC0730L2R2, we specialize in KEMET all series electronic components. MPLC0730L2R2 can be shipped within 24 hours after order. If you have any demands for MPLC0730L2R2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
MPLC0730L2R2 Order Process
Add Parts to RFQ form
Submit RFQ
We reply within 24 hours
You confirm order
Payment
Ship out your order
Specifications of MPLC0730L2R2
Internal Part NumberEIS-MPLC0730L2R2
Lead Free Status / RoHS StatusLead free / RoHS Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
Production Status (Lifecycle)In Production
ConditionNew & Unused, Original Sealed
Product Training ModulesMetal Composite SMD Power Inductors
Standard Package1,000
Category Inductors, Coils, Chokes
FamilyFixed Inductors
SeriesMPLC
PackagingTape & Reel (TR)
TypeWirewound
Material - Core-
Inductance2.2µH
Tolerance±20%
Current Rating7.3A
Current - Saturation8.2A
ShieldingUnshielded
DC Resistance (DCR)19 mOhm Max
Q @ Freq-
Frequency - Self Resonant-
Operating Temperature-20°C ~ 120°C
Frequency - Test100kHz
Mounting TypeSurface Mount
Package / CaseNonstandard
Size / Dimension0.315" L x 0.264" W (8.00mm x 6.70mm)
Height - Seated (Max)0.118" (3.00mm)
Supplier Device Package-
Weight0.001 KG
ApplicationEmail for details
Alternative Part (Replacement)MPLC0730L2R2
Related LinksMPLC07, MPLC0730L2R2 Datasheet, KEMET Distributor
MPLC0730L2R2 Details Description
