Microsemi Consumer Medical Product Group MT8815AP1
- Mfg. Part Number
- MT8815AP1
- Manufacturer
- Microsemi Consumer Medical Product Group
- Product Category
- Interface - Analog Switches, Multiplexers, Demultiplexers
- Brief Description
- IC ANLG SWITCH ARRAY 8X12 44PLCC
- Datasheet Download
- MT8815AP1.pdf
Availability of MT8815AP1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 12.29375
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MT8815AP1, we specialize in Microsemi Consumer Medical Product Group all series electronic components. MT8815AP1 can be shipped within 24 hours after order. If you have any demands for MT8815AP1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MT8815AP1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MT8815AP1
| Internal Part Number | EIS-MT8815AP1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 104 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers | |
| Series | - | |
| Packaging | Tube | |
| Function | Crosspoint Switch | |
| Circuit | 1 x 8:12 | |
| On-State Resistance | 65 Ohm | |
| Voltage Supply Source | Single Supply | |
| Voltage - Supply, Single/Dual (±) | 4.5 V ~ 13.2 V | |
| Current - Supply | - | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 44-LCC | |
| Supplier Device Package | 44-PLCC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MT8815AP1 | |
| Related Links | MT88, MT8815AP1 Datasheet, Microsemi Consumer Medical Product Group Distributor | |
