NJR/JRC Corporation NJU7600M#
- Mfg. Part Number
- NJU7600M#
- Manufacturer
- NJR/JRC Corporation
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG BOOST FLYBACK ADJ 8DMP
- Datasheet Download
- NJU7600M#.pdf
Availability of NJU7600M#
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.56420
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of NJU7600M#, we specialize in NJR/JRC Corporation all series electronic components. NJU7600M# can be shipped within 24 hours after order. If you have any demands for NJU7600M#, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- NJU7600M# Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
NJU7600M#
| Internal Part Number | EIS-NJU7600M# | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 100 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tube | |
| Function | Step-Up, Step-Up/Step-Down | |
| Output Configuration | Positive | |
| Topology | Boost, Flyback | |
| Output Type | Adjustable | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 2.2V | |
| Voltage - Input (Max) | 8V | |
| Voltage - Output (Min/Fixed) | - | |
| Voltage - Output (Max) | - | |
| Current - Output | - | |
| Frequency - Switching | 300kHz ~ 1MHz | |
| Synchronous Rectifier | No | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.209", 5.30mm Width) | |
| Supplier Device Package | 8-DMP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | NJU7600M# | |
| Related Links | NJU7, NJU7600M# Datasheet, NJR/JRC Corporation Distributor | |
NJU7600M# Details Description
