TDK Corporation NLCV25T-6R8M-PFD
- Mfg. Part Number
- NLCV25T-6R8M-PFD
- Manufacturer
- TDK Corporation
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 6.8UH 275MA 1.3 OHM
- Datasheet Download
- NLCV25T-6R8M-PFD.pdf
Availability of NLCV25T-6R8M-PFD
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.11643
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of NLCV25T-6R8M-PFD, we specialize in TDK Corporation all series electronic components. NLCV25T-6R8M-PFD can be shipped within 24 hours after order. If you have any demands for NLCV25T-6R8M-PFD, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- NLCV25T-6R8M-PFD Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
NLCV25T-6R8M-PFD
| Internal Part Number | EIS-NLCV25T-6R8M-PFD | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | Automotive, AEC-Q200, NLCV-PFD | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 6.8µH | |
| Tolerance | ±20% | |
| Current Rating | 275mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 1.3 Ohm Max | |
| Q @ Freq | 20 @ 7.96MHz | |
| Frequency - Self Resonant | 39MHz | |
| Operating Temperature | -40°C ~ 105°C | |
| Frequency - Test | 7.96MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 1008 (2520 Metric) | |
| Size / Dimension | 0.098" L x 0.079" W (2.50mm x 2.00mm) | |
| Height - Seated (Max) | 0.075" (1.90mm) | |
| Supplier Device Package | 1008 (2520 Metric) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | NLCV25T-6R8M-PFD | |
| Related Links | NLCV25T-, NLCV25T-6R8M-PFD Datasheet, TDK Corporation Distributor | |
NLCV25T-6R8M-PFD Details Description
