ON Semiconductor NP3500SCMCT3G
- Mfg. Part Number
- NP3500SCMCT3G
- Manufacturer
- ON Semiconductor
- Product Category
- TVS - Thyristors
- Brief Description
- THYRISTOR 320V 400A SMB
- Datasheet Download
- NP3500SCMCT3G.pdf
Availability of NP3500SCMCT3G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of NP3500SCMCT3G, we specialize in ON Semiconductor all series electronic components. NP3500SCMCT3G can be shipped within 24 hours after order. If you have any demands for NP3500SCMCT3G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- NP3500SCMCT3G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
NP3500SCMCT3G
| Internal Part Number | EIS-NP3500SCMCT3G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 19/Jul/2012 | |
| Standard Package | 2,500 | |
| Category | Circuit Protection | |
| Family | TVS - Thyristors | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Voltage - Breakover | 400V | |
| Voltage - Off State | 320V | |
| Voltage - On State | 4V | |
| Current - Peak Pulse (8/20µs) | 400A | |
| Current - Peak Pulse (10/1000µs) | 100A | |
| Current - Hold (Ih) | 150mA | |
| Number of Elements | 1 | |
| Capacitance | 33pF | |
| Package / Case | DO-214AA, SMB | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | NP3500SCMCT3G | |
| Related Links | NP3500, NP3500SCMCT3G Datasheet, ON Semiconductor Distributor | |
NP3500SCMCT3G Details Description
