Orion Fans OD4010-24MB01A
- Mfg. Part Number
- OD4010-24MB01A
- Manufacturer
- Orion Fans
- Product Category
- DC Fans
- Brief Description
- FAN AXIAL 40X10.5MM 24VDC WIRE
- Datasheet Download
- OD4010-24MB01A.pdf
Availability of OD4010-24MB01A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.70200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of OD4010-24MB01A, we specialize in Orion Fans all series electronic components. OD4010-24MB01A can be shipped within 24 hours after order. If you have any demands for OD4010-24MB01A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- OD4010-24MB01A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
OD4010-24MB01A
| Internal Part Number | EIS-OD4010-24MB01A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Standard Wire Colors For Fans | |
| Standard Package | 40 | |
| Category | Fans, Thermal Management | |
| Family | DC Fans | |
| Series | OD4010 | |
| Voltage - Rated | 24VDC | |
| Size / Dimension | Square - 40mm L x 40mm H x 10.5mm W | |
| Air Flow | 6.0 CFM (0.17m³/min) | |
| Static Pressure | 0.080 in H2O (19.9 Pa) | |
| Bearing Type | Ball | |
| Fan Type | Tubeaxial | |
| Features | Speed Sensor (Tach) | |
| Noise | 20 dB | |
| Power (Watts) | - | |
| RPM | 4800 RPM | |
| Termination | 3 Wire Leads | |
| Ingress Protection | - | |
| Weight | 0.001 KG | |
| Operating Temperature | -4 ~ 176°F (-20 ~ 80°C) | |
| Current Rating | 0.040A | |
| Voltage Range | 10 ~ 27VDC | |
| Life Expectancy | 60000 hrs @ 45°C | |
| Material - Frame | Polybutylene Terephthalate (PBT), Fiberglass Reinforced | |
| Material - Blade | Polybutylene Terephthalate (PBT), Fiberglass Reinforced | |
| Application | Email for details | |
| Alternative Part (Replacement) | OD4010-24MB01A | |
| Related Links | OD4010-, OD4010-24MB01A Datasheet, Orion Fans Distributor | |
OD4010-24MB01A Details Description
