Orion Fans OD7015-12MB
- Mfg. Part Number
- OD7015-12MB
- Manufacturer
- Orion Fans
- Product Category
- DC Fans
- Brief Description
- FAN AXIAL 70X15MM 12VDC WIRE
- Datasheet Download
- OD7015-12MB.pdf
Availability of OD7015-12MB
Available Quantity
5100 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.67012
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of OD7015-12MB, we specialize in Orion Fans all series electronic components. OD7015-12MB can be shipped within 24 hours after order. If you have any demands for OD7015-12MB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- OD7015-12MB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
OD7015-12MB
| Internal Part Number | EIS-OD7015-12MB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Standard Wire Colors For Fans | |
| Standard Package | 1 | |
| Category | Fans, Thermal Management | |
| Family | DC Fans | |
| Series | OD7015 | |
| Voltage - Rated | 12VDC | |
| Size / Dimension | Square - 70mm L x 70mm H x 15.5mm W | |
| Air Flow | 28.5 CFM (0.807m³/min) | |
| Static Pressure | - | |
| Bearing Type | Ball | |
| Fan Type | Tubeaxial | |
| Features | - | |
| Noise | 37 dB | |
| Power (Watts) | 2.16W | |
| RPM | 3500 RPM | |
| Termination | 2 Wire Leads | |
| Ingress Protection | - | |
| Weight | 0.001 KG | |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) | |
| Current Rating | 0.180A | |
| Voltage Range | 10.8 ~ 13.2VDC | |
| Life Expectancy | 70000 hrs @ 40°C | |
| Material - Frame | Polybutylene Terephthalate (PBT), Fiberglass Reinforced | |
| Material - Blade | Polybutylene Terephthalate (PBT), Fiberglass Reinforced | |
| Application | Email for details | |
| Alternative Part (Replacement) | OD7015-12MB | |
| Related Links | OD701, OD7015-12MB Datasheet, Orion Fans Distributor | |
