Panduit P22-4F-M
- Mfg. Part Number
- P22-4F-M
- Manufacturer
- Panduit
- Product Category
- Terminals - Spade Connectors
- Brief Description
- TERM FORK NON INS 26-22AWG #4
- Datasheet Download
- P22-4F-M.pdf
Availability of P22-4F-M
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.12310
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of P22-4F-M, we specialize in Panduit all series electronic components. P22-4F-M can be shipped within 24 hours after order. If you have any demands for P22-4F-M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- P22-4F-M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
P22-4F-M
| Internal Part Number | EIS-P22-4F-M | |
| Lead Free Status / RoHS Status | ||
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Connectors, Interconnects | |
| Family | Terminals - Spade Connectors | |
| Series | Pan-Term® | |
| Packaging | Bulk | |
| Terminal Type | Standard | |
| Stud/Tab Size | 4 Stud | |
| Width - Outer Edges | 0.190" (4.83mm) | |
| Length - Overall | 0.490" (12.45mm) | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Crimp | |
| Wire Gauge | 22-26 AWG | |
| Insulation | Non-Insulated | |
| Features | Brazed Seam | |
| Color | - | |
| Contact Finish | Tin | |
| Contact Material | Copper | |
| Insulation Diameter | - | |
| Material - Insulation | - | |
| Length - Ring Center to Termination | - | |
| Length - Termination | - | |
| Tongue Inside Opening | 0.130" (3.30mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | P22-4F-M | |
| Related Links | P22-, P22-4F-M Datasheet, Panduit Distributor | |
P22-4F-M Details Description
