3M P50L-040P-RR5-DA
- Mfg. Part Number
- P50L-040P-RR5-DA
- Manufacturer
- 3M
- Product Category
- Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine
- Brief Description
- CONN PLUG 40POS R/A .050" GOL
- Datasheet Download
- P50L-040P-RR5-DA.pdf
Availability of P50L-040P-RR5-DA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.71548
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of P50L-040P-RR5-DA, we specialize in 3M all series electronic components. P50L-040P-RR5-DA can be shipped within 24 hours after order. If you have any demands for P50L-040P-RR5-DA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- P50L-040P-RR5-DA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
P50L-040P-RR5-DA
| Internal Part Number | EIS-P50L-040P-RR5-DA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Interconnect Mating Guide | |
| Standard Package | 208 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine | |
| Series | Pak 50, P50L | |
| Packaging | Bulk | |
| Connector Type | Plug, Center Strip Contacts | |
| Number of Positions | 40 | |
| Pitch | 0.050" (1.27mm) | |
| Number of Rows | 2 | |
| Mounting Type | Through Hole, Right Angle | |
| Features | Board Lock | |
| Contact Finish | Gold | |
| Contact Finish Thickness | Flash | |
| Mated Stacking Heights | - | |
| Height Above Board | 0.374" (9.50mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | P50L-040P-RR5-DA | |
| Related Links | P50L-040, P50L-040P-RR5-DA Datasheet, 3M Distributor | |
P50L-040P-RR5-DA Details Description
