Sullins Connector Solutions PBC28DBDN
- Mfg. Part Number
- PBC28DBDN
- Manufacturer
- Sullins Connector Solutions
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- CONN HEADER .100 DUAL R/A 56POS
- Datasheet Download
- PBC28DBDN.pdf
Availability of PBC28DBDN
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 4.02906
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PBC28DBDN, we specialize in Sullins Connector Solutions all series electronic components. PBC28DBDN can be shipped within 24 hours after order. If you have any demands for PBC28DBDN, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PBC28DBDN Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PBC28DBDN
| Internal Part Number | EIS-PBC28DBDN | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | - | |
| Packaging | Bulk | |
| Contact Type | Male Pin | |
| Connector Type | Header, Unshrouded, Breakaway | |
| Number of Positions | 56 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.100" (2.54mm) | |
| Contact Mating Length | 0.230" (5.84mm) | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 10µin (0.25µm) | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PBC28DBDN | |
| Related Links | PBC2, PBC28DBDN Datasheet, Sullins Connector Solutions Distributor | |
