Texas Instruments PCM2904DB
- Mfg. Part Number
- PCM2904DB
- Manufacturer
- Texas Instruments
- Product Category
- Interface - CODECs
- Brief Description
- IC STEREO AUD CODEC W/USB 28SSOP
- Datasheet Download
- PCM2904DB.pdf
Availability of PCM2904DB
Available Quantity
5138 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.85625
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PCM2904DB, we specialize in Texas Instruments all series electronic components. PCM2904DB can be shipped within 24 hours after order. If you have any demands for PCM2904DB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PCM2904DB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PCM2904DB
| Internal Part Number | EIS-PCM2904DB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Lead Frame Base Update 02/Apr/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 47 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - CODECs | |
| Series | - | |
| Packaging | Tube | |
| Type | Stereo Audio | |
| Data Interface | USB | |
| Resolution (Bits) | 16 b | |
| Number of ADCs / DACs | 2 / 2 | |
| Sigma Delta | Yes | |
| S/N Ratio, ADCs / DACs (db) Typ | 89 / 96 | |
| Dynamic Range, ADCs / DACs (db) Typ | 89 / 93 | |
| Voltage - Supply, Analog | 4.35 V ~ 5.25 V | |
| Voltage - Supply, Digital | 4.35 V ~ 5.25 V | |
| Operating Temperature | -25°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 28-SSOP (0.209", 5.30mm Width) | |
| Supplier Device Package | 28-SSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PCM2904DB | |
| Related Links | PCM2, PCM2904DB Datasheet, Texas Instruments Distributor | |
PCM2904DB Details Description
