Texas Instruments PCM3000E
- Mfg. Part Number
- PCM3000E
- Manufacturer
- Texas Instruments
- Product Category
- Interface - CODECs
- Brief Description
- IC AUDIO CODEC 18-BIT 28-SSOP
- Datasheet Download
- PCM3000E.pdf
Availability of PCM3000E
Available Quantity
5632 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.24250
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PCM3000E, we specialize in Texas Instruments all series electronic components. PCM3000E can be shipped within 24 hours after order. If you have any demands for PCM3000E, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PCM3000E Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PCM3000E
| Internal Part Number | EIS-PCM3000E | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Lead Frame Base Update 02/Apr/2015 | |
| Standard Package | 47 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - CODECs | |
| Series | - | |
| Packaging | Tube | |
| Type | Stereo Audio | |
| Data Interface | Serial | |
| Resolution (Bits) | 18 b | |
| Number of ADCs / DACs | 2 / 2 | |
| Sigma Delta | Yes | |
| S/N Ratio, ADCs / DACs (db) Typ | 94 / 98 | |
| Dynamic Range, ADCs / DACs (db) Typ | 94 / 97 | |
| Voltage - Supply, Analog | 4.5 V ~ 5.5 V | |
| Voltage - Supply, Digital | 4.5 V ~ 5.5 V | |
| Operating Temperature | -25°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 28-SSOP (0.209", 5.30mm Width) | |
| Supplier Device Package | 28-SSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PCM3000E | |
| Related Links | PCM3, PCM3000E Datasheet, Texas Instruments Distributor | |
PCM3000E Details Description
