Texas Instruments PCM4202DBR
- Mfg. Part Number
- PCM4202DBR
- Manufacturer
- Texas Instruments
- Product Category
- Data Acquisition - ADCs/DACs - Special Purpose
- Brief Description
- IC ADC 24BIT 216KHZ SAMP 28-SSOP
- Datasheet Download
- PCM4202DBR.pdf
Availability of PCM4202DBR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 4.46625
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PCM4202DBR, we specialize in Texas Instruments all series electronic components. PCM4202DBR can be shipped within 24 hours after order. If you have any demands for PCM4202DBR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PCM4202DBR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PCM4202DBR
| Internal Part Number | EIS-PCM4202DBR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Data Converter Basics | |
| PCN Packaging | Carrier Tape Update 23/Feb/2015 Carrier Tape Revision A 06/Mar/2015 Carrier Tape Revision B 30/Mar/2015 Carrier Tape Revision C 09/Apr/2015 PCN Cancelled 17/Apr/2015 | |
| PCN Other | DW,DB,PW,DBT Packages 28/Mar/2013 | |
| Manufacturer Product Page | PCM4202DBR Specifications | |
| Standard Package | 1,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - ADCs/DACs - Special Purpose | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | ADC, Audio | |
| Resolution (Bits) | 24 b | |
| Sampling Rate (Per Second) | 216k | |
| Data Interface | DSP, PCM | |
| Voltage Supply Source | Analog and Digital | |
| Voltage - Supply | 1.65 V ~ 3.6 V, 5V | |
| Operating Temperature | -10°C ~ 70°C | |
| Mounting Type | * | |
| Package / Case | 28-SSOP (0.209", 5.30mm Width) | |
| Supplier Device Package | 28-SSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PCM4202DBR | |
| Related Links | PCM42, PCM4202DBR Datasheet, Texas Instruments Distributor | |
PCM4202DBR Details Description
