Advanced Photonix, Inc. PDB-C140
- Mfg. Part Number
- PDB-C140
- Manufacturer
- Advanced Photonix, Inc.
- Product Category
- Optical Sensors - Photodiodes
- Brief Description
- PHOTODIODE BLUE 29.02MM SQ CER
- Datasheet Download
- PDB-C140.pdf
Availability of PDB-C140
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 38.80940
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PDB-C140, we specialize in Advanced Photonix, Inc. all series electronic components. PDB-C140 can be shipped within 24 hours after order. If you have any demands for PDB-C140, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PDB-C140 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PDB-C140
| Internal Part Number | EIS-PDB-C140 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Single-Element Silicon Pin Photodiodes | |
| Standard Package | 250 | |
| Category | Sensors, Transducers | |
| Family | Optical Sensors - Photodiodes | |
| Series | - | |
| Packaging | Bulk | |
| Wavelength | 940nm | |
| Color - Enhanced | Blue | |
| Spectral Range | 350nm ~ 1100nm | |
| Diode Type | PIN | |
| Responsivity @ nm | 0.18 A/W @ 450nm | |
| Response Time | 13ns | |
| Voltage - DC Reverse (Vr) (Max) | 75V | |
| Current - Dark (Typ) | 10nA | |
| Active Area | 29.03mm² | |
| Viewing Angle | 120° | |
| Operating Temperature | -40°C ~ 100°C | |
| Mounting Type | Through Hole | |
| Package / Case | Radial | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PDB-C140 | |
| Related Links | PDB-, PDB-C140 Datasheet, Advanced Photonix, Inc. Distributor | |
PDB-C140 Details Description
