Bourns Inc. PEC11R-4230F-S0024
- Mfg. Part Number
- PEC11R-4230F-S0024
- Manufacturer
- Bourns Inc.
- Product Category
- Encoders
- Brief Description
- ENCODER
- Datasheet Download
- PEC11R-4230F-S0024.pdf
Availability of PEC11R-4230F-S0024
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.87000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PEC11R-4230F-S0024, we specialize in Bourns Inc. all series electronic components. PEC11R-4230F-S0024 can be shipped within 24 hours after order. If you have any demands for PEC11R-4230F-S0024, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PEC11R-4230F-S0024 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PEC11R-4230F-S0024
| Internal Part Number | EIS-PEC11R-4230F-S0024 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Packaging | PEC11R, PEC12R and PEC11L Series 24/Dec/2014 | |
| Standard Package | 75 | |
| Category | Sensors, Transducers | |
| Family | Encoders | |
| Series | PEC11R | |
| Encoder Type | Mechanical | |
| Output Type | Quadrature (Incremental) | |
| Pulses per Revolution | 24 | |
| Voltage - Supply | - | |
| Actuator Type | 6mm Dia Flatted End | |
| Detent | Yes | |
| Built in Switch | Yes | |
| Mounting Type | Panel, PCB Through Hole | |
| Orientation | Vertical | |
| Termination Style | PC Pin | |
| Rotational Life (Cycles Min) | 30K | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PEC11R-4230F-S0024 | |
| Related Links | PEC11R-42, PEC11R-4230F-S0024 Datasheet, Bourns Inc. Distributor | |
PEC11R-4230F-S0024 Details Description
