CUI Inc. PEM2-S5-S15-S
- Mfg. Part Number
- PEM2-S5-S15-S
- Manufacturer
- CUI Inc.
- Product Category
- DC DC Converters
- Brief Description
- CONVERT DC/DC 2W 15V 133MA OUT
- Datasheet Download
- PEM2-S5-S15-S.pdf
Availability of PEM2-S5-S15-S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.99200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PEM2-S5-S15-S, we specialize in CUI Inc. all series electronic components. PEM2-S5-S15-S can be shipped within 24 hours after order. If you have any demands for PEM2-S5-S15-S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PEM2-S5-S15-S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PEM2-S5-S15-S
| Internal Part Number | EIS-PEM2-S5-S15-S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Low Power DC-DC Converters EMI Regulations and Mitigation Considerations for Switching Power Supplies Reliability Considerations for Power Supplies Power Supply Safety Standards, Agencies and Marks Thermal Management of Power Supplies | |
| RoHS Information | PEM2-S Series Cert of Compliance | |
| Featured Product | CUI - High Isolation 1 W - 2 W SIP DC-DC Converters | |
| 3D Model | PEM2-S5-S15-S | |
| Standard Package | 25 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | PEM2-S | |
| Packaging | Tube | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 5.5V | |
| Voltage - Output 1 | 15V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 133.3mA | |
| Power (Watts) - Manufacture Series | 2W | |
| Voltage - Isolation | 3kV (3000V) | |
| Features | SCP | |
| Mounting Type | Through Hole | |
| Package / Case | 7-SIP Module (4 Leads) | |
| Size / Dimension | 0.77" L x 0.28" W x 0.39" H (19.6mm x 7.0mm x 10.0mm) | |
| Operating Temperature | -40°C ~ 105°C | |
| Efficiency | 84% | |
| Power (Watts) - Max | 2W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PEM2-S5-S15-S | |
| Related Links | PEM2-S, PEM2-S5-S15-S Datasheet, CUI Inc. Distributor | |
PEM2-S5-S15-S Details Description
