TDK Corporation PFC3318QM-601K03B-00
- Mfg. Part Number
- PFC3318QM-601K03B-00
- Manufacturer
- TDK Corporation
- Product Category
- Common Mode Chokes
- Brief Description
- CHOKE COMMON MODE
- Datasheet Download
- PFC3318QM-601K03B-00.pdf
Availability of PFC3318QM-601K03B-00
Available Quantity
5055 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 11.09220
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PFC3318QM-601K03B-00, we specialize in TDK Corporation all series electronic components. PFC3318QM-601K03B-00 can be shipped within 24 hours after order. If you have any demands for PFC3318QM-601K03B-00, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PFC3318QM-601K03B-00 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PFC3318QM-601K03B-00
| Internal Part Number | EIS-PFC3318QM-601K03B-00 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 35 | |
| Category | Filters | |
| Family | Common Mode Chokes | |
| Series | PFC | |
| Packaging | Bulk | |
| Filter Type | Power Line | |
| Number of Lines | 2 | |
| Inductance | 600µH | |
| Current | 2.8A | |
| DC Resistance (DCR) | - | |
| Impedance | - | |
| Operating Temperature | -30°C ~ 120°C | |
| Mounting Type | Through Hole | |
| Size / Dimension | 1.102" L x 1.378" W (28.00mm x 35.00mm) | |
| Height (Max) | 0.787" (20.00mm) | |
| Package / Case | Vertical, 8 PC Pin | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PFC3318QM-601K03B-00 | |
| Related Links | PFC3318QM-, PFC3318QM-601K03B-00 Datasheet, TDK Corporation Distributor | |
PFC3318QM-601K03B-00 Details Description
