Panduit PH10-14R-E
- Mfg. Part Number
- PH10-14R-E
- Manufacturer
- Panduit
- Product Category
- Terminals - Ring Connectors
- Brief Description
- TERM RING HT SHR 12-10AWG YL 1/4
- Datasheet Download
- PH10-14R-E.pdf
Availability of PH10-14R-E
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.66700
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PH10-14R-E, we specialize in Panduit all series electronic components. PH10-14R-E can be shipped within 24 hours after order. If you have any demands for PH10-14R-E, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PH10-14R-E Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PH10-14R-E
| Internal Part Number | EIS-PH10-14R-E | |
| Lead Free Status / RoHS Status | ||
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 20 | |
| Category | Connectors, Interconnects | |
| Family | Terminals - Ring Connectors | |
| Series | Pan-Term® | |
| Packaging | Bulk | |
| Terminal Type | Circular | |
| Stud/Tab Size | 1/4 Stud | |
| Thickness | - | |
| Width - Outer Edges | 0.520" (13.21mm) | |
| Length - Overall | 1.200" (30.48mm) | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Crimp | |
| Wire Gauge | 10-12 AWG | |
| Insulation | Insulated with Heat Shrink | |
| Features | Brazed Seam | |
| Color | Yellow | |
| Contact Material | Copper | |
| Contact Finish | Tin | |
| Insulation Diameter | 0.240" (6.10mm) | |
| Material - Insulation | Polyolefin | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PH10-14R-E | |
| Related Links | PH10-, PH10-14R-E Datasheet, Panduit Distributor | |
