Vishay Thin Film PHP00805E66R5BST1

PHP00805E66R5BST1 picture photo
Mfg. Part Number
PHP00805E66R5BST1
Manufacturer
Product Category
Chip Resistor - Surface Mount
Brief Description
RES SMD 66.5 OHM 0.1% 5/8W 0805
Datasheet Download
PHP00805E66R5BST1.pdf
Availability of PHP00805E66R5BST1

Available Quantity

5020 Pieces

Can ship today

Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks

Marketing Price
$ 0.62510
Our Price
Quote by Email

QUANTITY



EIS Components is the stocking Distributor of PHP00805E66R5BST1, we specialize in Vishay Thin Film all series electronic components. PHP00805E66R5BST1 can be shipped within 24 hours after order. If you have any demands for PHP00805E66R5BST1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
PHP00805E66R5BST1 Order Process
Add Parts to RFQ form
Submit RFQ
We reply within 24 hours
You confirm order
Payment
Ship out your order
Specifications of PHP00805E66R5BST1
Internal Part NumberEIS-PHP00805E66R5BST1
Lead Free Status / RoHS StatusLead free / RoHS Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
Production Status (Lifecycle)In Production
ConditionNew & Unused, Original Sealed
Product Training ModulesThin Film PHP Chip Resistors
Standard Package1,000
Category Resistors
FamilyChip Resistor - Surface Mount
SeriesPHP
PackagingTape & Reel (TR)
Resistance (Ohms)66.5
Tolerance±0.1%
Power (Watts)0.63W, 5/8W
CompositionThin Film
FeaturesFlame Proof, Moisture Resistant, Safety
Temperature Coefficient±25ppm/°C
Operating Temperature-55°C ~ 155°C
Package / Case0805 (2012 Metric)
Supplier Device Package0805
Size / Dimension0.080" L x 0.050" W (2.03mm x 1.27mm)
Height0.033" (0.84mm)
Number of Terminations2
Weight0.001 KG
ApplicationEmail for details
Alternative Part (Replacement)PHP00805E66R5BST1
Related LinksPHP00805, PHP00805E66R5BST1 Datasheet, Vishay Thin Film Distributor
PHP00805E66R5BST1 Details Description
