Pericom Semiconductor Corp. PI2DBS212ZHEX
- Mfg. Part Number
- PI2DBS212ZHEX
- Manufacturer
- Pericom Semiconductor Corp.
- Product Category
- Interface - Analog Switches, Multiplexers, Demultiplexers
- Brief Description
- IC MUX/DEMUX 2X1 28TQFN
- Datasheet Download
- PI2DBS212ZHEX.pdf
Availability of PI2DBS212ZHEX
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.87750
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PI2DBS212ZHEX, we specialize in Pericom Semiconductor Corp. all series electronic components. PI2DBS212ZHEX can be shipped within 24 hours after order. If you have any demands for PI2DBS212ZHEX, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PI2DBS212ZHEX Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PI2DBS212ZHEX
| Internal Part Number | EIS-PI2DBS212ZHEX | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | High Speed Switch Solutions | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 3,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Function | Multiplexer/Demultiplexer | |
| Circuit | 2 x 2:1 | |
| On-State Resistance | 10 Ohm | |
| Voltage Supply Source | Single Supply | |
| Voltage - Supply, Single/Dual (±) | 1.2 V ~ 1.8 V | |
| Current - Supply | - | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 28-VFQFN Exposed Pad | |
| Supplier Device Package | 28-TQFN-EP (3.5x5.5) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PI2DBS212ZHEX | |
| Related Links | PI2DBS, PI2DBS212ZHEX Datasheet, Pericom Semiconductor Corp. Distributor | |
PI2DBS212ZHEX Details Description
