Pericom Semiconductor Corp. PI5C6800L
- Mfg. Part Number
- PI5C6800L
- Manufacturer
- Pericom Semiconductor Corp.
- Product Category
- Logic - Signal Switches, Multiplexers, Decoders
- Brief Description
- IC 10-BIT PCI BUS SW 24-TSSOP
- Datasheet Download
- PI5C6800L.pdf
Availability of PI5C6800L
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PI5C6800L, we specialize in Pericom Semiconductor Corp. all series electronic components. PI5C6800L can be shipped within 24 hours after order. If you have any demands for PI5C6800L, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PI5C6800L Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PI5C6800L
| Internal Part Number | EIS-PI5C6800L | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 11/Feb/2008 Multiple Devices 11/Feb/2008 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 62 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Signal Switches, Multiplexers, Decoders | |
| Series | - | |
| Packaging | Tube | |
| Type | Bus Switch | |
| Circuit | 10 x 1:1 | |
| Independent Circuits | 1 | |
| Current - Output High, Low | - | |
| Voltage Supply Source | Single Supply | |
| Voltage - Supply | 4 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 24-TSSOP (0.173", 4.40mm Width) | |
| Supplier Device Package | 24-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PI5C6800L | |
| Related Links | PI5C, PI5C6800L Datasheet, Pericom Semiconductor Corp. Distributor | |
PI5C6800L Details Description
