Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
| Internal Part Number | EIS-PI74FCT543ATS | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 08/Jul/2005 | |
| Standard Package | 31 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Buffers, Drivers, Receivers, Transceivers | |
| Series | 74FCT | |
| Packaging | Tube | |
| Logic Type | Registered Transceiver, Non-Inverting | |
| Number of Elements | 1 | |
| Number of Bits per Element | 8 | |
| Current - Output High, Low | 15mA, 64mA | |
| Voltage - Supply | 4.75 V ~ 5.25 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 24-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 24-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PI74FCT543ATS | |
| Related Links | PI74FC, PI74FCT543ATS Datasheet, Pericom Semiconductor Corp. Distributor | |
