Microchip Technology PIC16F877-04E/PQ
- Mfg. Part Number
- PIC16F877-04E/PQ
- Manufacturer
- Microchip Technology
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 8BIT 14KB FLASH 44MQFP
- Datasheet Download
- PIC16F877-04E/PQ.pdf
Availability of PIC16F877-04E/PQ
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 7.85000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PIC16F877-04E/PQ, we specialize in Microchip Technology all series electronic components. PIC16F877-04E/PQ can be shipped within 24 hours after order. If you have any demands for PIC16F877-04E/PQ, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PIC16F877-04E/PQ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PIC16F877-04E/PQ
| Internal Part Number | EIS-PIC16F877-04E/PQ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Asynchronous Stimulus | |
| Design Resources | Development Tool Selector | |
| PCN Design/Specification | Copper/Gold Bond Wire 07/Apr/2015 | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Standard Package | 96 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | PIC® 16F | |
| Packaging | Tray | |
| Core Processor | PIC | |
| Core Size | 8-Bit | |
| Speed | 4MHz | |
| Connectivity | I²C, SPI, UART/USART | |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT | |
| Number of I/O | 33 | |
| Program Memory Size | 14KB (8K x 14) | |
| Program Memory Type | FLASH | |
| EEPROM Size | 256 x 8 | |
| RAM Size | 368 x 8 | |
| Voltage - Supply (Vcc/Vdd) | 4 V ~ 5.5 V | |
| Data Converters | A/D 8x10b | |
| Oscillator Type | External | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 44-QFP | |
| Supplier Device Package | 44-MQFP (10x10) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PIC16F877-04E/PQ | |
| Related Links | PIC16F87, PIC16F877-04E/PQ Datasheet, Microchip Technology Distributor | |
PIC16F877-04E/PQ Details Description
