Microchip Technology PIC16HV753-I/SL
- Mfg. Part Number
- PIC16HV753-I/SL
- Manufacturer
- Microchip Technology
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 8BIT 3.5KB FLASH 14SOIC
- Datasheet Download
- PIC16HV753-I/SL.pdf
Availability of PIC16HV753-I/SL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.72000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PIC16HV753-I/SL, we specialize in Microchip Technology all series electronic components. PIC16HV753-I/SL can be shipped within 24 hours after order. If you have any demands for PIC16HV753-I/SL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PIC16HV753-I/SL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PIC16HV753-I/SL
| Internal Part Number | EIS-PIC16HV753-I/SL | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| PCN Design/Specification | PIC16F753/HV753 Errata/Datasheet Update 19/Aug/2013 PIC16F753,HV753 Datasheet Revision 20/Nov/2013 Errata/Datasheet Update 07/Aug/2014 Datasheet Update 12/Mar/2015 Copper Bond Wire 5/Nov/2015 | |
| PCN Assembly/Origin | Qualification Copper Bond Wire 31/Oct/2014 | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Standard Package | 57 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | PIC® 16F | |
| Packaging | Tube | |
| Core Processor | PIC | |
| Core Size | 8-Bit | |
| Speed | 20MHz | |
| Connectivity | - | |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT | |
| Number of I/O | 11 | |
| Program Memory Size | 3.5KB (2K x 14) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 128 x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2 V ~ 5 V | |
| Data Converters | A/D 8x10b, D/A 1x9b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 14-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PIC16HV753-I/SL | |
| Related Links | PIC16HV, PIC16HV753-I/SL Datasheet, Microchip Technology Distributor | |
PIC16HV753-I/SL Details Description
