Microchip Technology PIC18LF14K50T-I/SS
- Mfg. Part Number
- PIC18LF14K50T-I/SS
- Manufacturer
- Microchip Technology
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 8BIT 16KB FLASH 20SSOP
- Datasheet Download
- PIC18LF14K50T-I/SS.pdf
Availability of PIC18LF14K50T-I/SS
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.79000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PIC18LF14K50T-I/SS, we specialize in Microchip Technology all series electronic components. PIC18LF14K50T-I/SS can be shipped within 24 hours after order. If you have any demands for PIC18LF14K50T-I/SS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PIC18LF14K50T-I/SS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PIC18LF14K50T-I/SS
| Internal Part Number | EIS-PIC18LF14K50T-I/SS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| PCN Assembly/Origin | Qualification Copper Wire 20/Oct/2014 | |
| PCN Packaging | Reel Design Update 07/May/2015 Label and Packing Changes 23/Sep/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,600 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | PIC® XLP™ 18K | |
| Packaging | Tape & Reel (TR) | |
| Core Processor | PIC | |
| Core Size | 8-Bit | |
| Speed | 48MHz | |
| Connectivity | I²C, SPI, UART/USART, USB | |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT | |
| Number of I/O | 14 | |
| Program Memory Size | 16KB (8K x 16) | |
| Program Memory Type | FLASH | |
| EEPROM Size | 256 x 8 | |
| RAM Size | 768 x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.8 V ~ 3.6 V | |
| Data Converters | A/D 11x10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 20-SSOP (0.209", 5.30mm Width) | |
| Supplier Device Package | 20-SSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PIC18LF14K50T-I/SS | |
| Related Links | PIC18LF14, PIC18LF14K50T-I/SS Datasheet, Microchip Technology Distributor | |
