Microchip Technology PIC18LF26K22T-I/ML
- Mfg. Part Number
- PIC18LF26K22T-I/ML
- Manufacturer
- Microchip Technology
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 8BIT 64KB FLASH 28QFN
- Datasheet Download
- PIC18LF26K22T-I/ML.pdf
Availability of PIC18LF26K22T-I/ML
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.34000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PIC18LF26K22T-I/ML, we specialize in Microchip Technology all series electronic components. PIC18LF26K22T-I/ML can be shipped within 24 hours after order. If you have any demands for PIC18LF26K22T-I/ML, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PIC18LF26K22T-I/ML Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PIC18LF26K22T-I/ML
| Internal Part Number | EIS-PIC18LF26K22T-I/ML | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| PCN Design/Specification | Mold Compound Update 31/Oct/2014 Lead Frame Update 16/Feb/2015 | |
| PCN Assembly/Origin | Qualification QFN-28,20,16 Packages 26/Dec/2013 Qualification QFN-28,20,16 with Copper 09/Jan/2014 Qualification Report 28/Jan/2014 Qualification Copper Wire Revison 01/Apr/2014 Cancelation of Copper Assembly 25/Jun/2015 | |
| PCN Packaging | Reel Design Update 07/May/2015 Label and Packing Changes 23/Sep/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,600 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | PIC® XLP™ 18K | |
| Packaging | Tape & Reel (TR) | |
| Core Processor | PIC | |
| Core Size | 8-Bit | |
| Speed | 64MHz | |
| Connectivity | I²C, SPI, UART/USART | |
| Peripherals | Brown-out Detect/Reset, HLVD, POR, PWM, WDT | |
| Number of I/O | 24 | |
| Program Memory Size | 64KB (32K x 16) | |
| Program Memory Type | FLASH | |
| EEPROM Size | 1K x 8 | |
| RAM Size | 3.8K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.8 V ~ 3.6 V | |
| Data Converters | A/D 19x10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 28-VQFN Exposed Pad | |
| Supplier Device Package | 28-QFN (6x6) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PIC18LF26K22T-I/ML | |
| Related Links | PIC18LF26, PIC18LF26K22T-I/ML Datasheet, Microchip Technology Distributor | |
PIC18LF26K22T-I/ML Details Description
