Microchip Technology PIC32MZ2048ECH064-I/MR
- Mfg. Part Number
- PIC32MZ2048ECH064-I/MR
- Manufacturer
- Microchip Technology
- Product Category
- Embedded - Microcontrollers
- Brief Description
- MCU 32BIT 2048KB FLASH 64QFN
- Datasheet Download
- PIC32MZ2048ECH064-I/MR.pdf
Availability of PIC32MZ2048ECH064-I/MR
Available Quantity
5119 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.22000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PIC32MZ2048ECH064-I/MR, we specialize in Microchip Technology all series electronic components. PIC32MZ2048ECH064-I/MR can be shipped within 24 hours after order. If you have any demands for PIC32MZ2048ECH064-I/MR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PIC32MZ2048ECH064-I/MR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PIC32MZ2048ECH064-I/MR
| Internal Part Number | EIS-PIC32MZ2048ECH064-I/MR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Bluetooth Audio Development Platform | |
| Design Resources | Development Tool Selector | |
| PCN Design/Specification | PIC32MZ EC Errata/Datasheet Update 16/Dec/2013 PIC32MZ Datasheet Update 06/May/2014 PIC32MZ Errata/Datasheet Update 04/Jun/2014 PIC32MZ Datasheet Update 04/Jul/2014 PIC32MZ Errata/Datasheet Update 13/Oct/2014 PIC32MZ Die Update 13/Oct/2014 Mold Compound Update 31/Oct/2014 Errata/Datasheet Update 16/Dec/2014 Lead Frame Update 16/Feb/2015 Dattasheet Update 07/Apr/2015 Errata/Datasheet Update 31/Jul/2015 Errata/Datasheet Update 22/Sep/2015 | |
| PCN Assembly/Origin | Assembly Site Addition 22/Jun/2015 | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Standard Package | 40 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | PIC® 32MZ | |
| Packaging | Tube | |
| Core Processor | MIPS32® microAptiv™ | |
| Core Size | 32-Bit | |
| Speed | 200MHz | |
| Connectivity | CAN, Ethernet, I²C, SPI, SQI, UART/USART, USB OTG | |
| Peripherals | Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT | |
| Number of I/O | 53 | |
| Program Memory Size | 2MB (2M x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 512K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2.3 V ~ 3.6 V | |
| Data Converters | A/D 24x12b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 64-VFQFN Exposed Pad | |
| Supplier Device Package | 64-QFN Exposed Pad (9x9) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PIC32MZ2048ECH064-I/MR | |
| Related Links | PIC32MZ2048, PIC32MZ2048ECH064-I/MR Datasheet, Microchip Technology Distributor | |
