Bivar, Inc. PM5ATW12.0
- Mfg. Part Number
- PM5ATW12.0
- Manufacturer
- Bivar, Inc.
- Product Category
- Panel Indicators, Pilot Lights
- Brief Description
- PNL MNT AMBER W/WIRE 12"
- Datasheet Download
- PM5ATW12.0.pdf
Availability of PM5ATW12.0
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.23840
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PM5ATW12.0, we specialize in Bivar, Inc. all series electronic components. PM5ATW12.0 can be shipped within 24 hours after order. If you have any demands for PM5ATW12.0, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PM5ATW12.0 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PM5ATW12.0
| Internal Part Number | EIS-PM5ATW12.0 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | PM5xxWxx.x.igs | |
| Standard Package | 100 | |
| Category | Optoelectronics | |
| Family | Panel Indicators, Pilot Lights | |
| Series | PM5 | |
| Type | LED | |
| Lamp Color | Amber | |
| Lens Color | Colorless | |
| Lens Transparency | Clear | |
| Ratings | Vf (Typ), If (Max) | |
| Voltage | 2V | |
| Current | 30mA | |
| Panel Cutout Shape | Round | |
| Panel Cutout Dimensions | 0.25" (6.35mm) | |
| Lens Style/Size | Round with Domed Top, 5mm (T-1 3/4) | |
| Millicandela Rating | 40mcd | |
| Wavelength - Peak | 605nm | |
| Viewing Angle | 35° | |
| Termination Style | Wire Leads - 12" (304.80mm) | |
| Ingress Protection | - | |
| Features | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PM5ATW12.0 | |
| Related Links | PM5AT, PM5ATW12.0 Datasheet, Bivar, Inc. Distributor | |
