Sharp Microelectronics PQ1U221M2ZPH
- Mfg. Part Number
- PQ1U221M2ZPH
- Manufacturer
- Sharp Microelectronics
- Product Category
- PMIC - Voltage Regulators - Linear
- Brief Description
- IC REG LDO 2.2V 0.15A SOT23-5
- Datasheet Download
- PQ1U221M2ZPH.pdf
Availability of PQ1U221M2ZPH
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PQ1U221M2ZPH, we specialize in Sharp Microelectronics all series electronic components. PQ1U221M2ZPH can be shipped within 24 hours after order. If you have any demands for PQ1U221M2ZPH, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PQ1U221M2ZPH Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PQ1U221M2ZPH
| Internal Part Number | EIS-PQ1U221M2ZPH | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - Linear | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Regulator Topology | Positive Fixed | |
| Voltage - Output | 2.2V | |
| Current - Output | 150mA | |
| Voltage - Dropout (Typical) | 0.2V @ 150mA | |
| Number of Regulators | 1 | |
| Voltage - Input | Up to 16V | |
| Current - Limit (Min) | 180mA | |
| Operating Temperature | -30°C ~ 80°C | |
| Mounting Type | Surface Mount | |
| Package / Case | SC-74A, SOT-753 | |
| Supplier Device Package | SOT-23-5 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PQ1U221M2ZPH | |
| Related Links | PQ1U22, PQ1U221M2ZPH Datasheet, Sharp Microelectronics Distributor | |
PQ1U221M2ZPH Details Description
