JAE Electronics PS-60SD-D4T1-1
- Mfg. Part Number
- PS-60SD-D4T1-1
- Manufacturer
- JAE Electronics
- Product Category
- Rectangular Connectors - Headers, Receptacles, Female Sockets
- Brief Description
- CONN HEADER 60POS
- Datasheet Download
- PS-60SD-D4T1-1.pdf
Availability of PS-60SD-D4T1-1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 16.14400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PS-60SD-D4T1-1, we specialize in JAE Electronics all series electronic components. PS-60SD-D4T1-1 can be shipped within 24 hours after order. If you have any demands for PS-60SD-D4T1-1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PS-60SD-D4T1-1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PS-60SD-D4T1-1
| Internal Part Number | EIS-PS-60SD-D4T1-1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Receptacles, Female Sockets | |
| Series | PS | |
| Packaging | Bulk | |
| Connector Type | Receptacle | |
| Contact Type | Female Socket | |
| Number of Positions | 60 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.100" (2.54mm) | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 3.9µin (0.10µm) | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PS-60SD-D4T1-1 | |
| Related Links | PS-60SD, PS-60SD-D4T1-1 Datasheet, JAE Electronics Distributor | |
