Parlex Corp. PS563-AB-0254-S
- Mfg. Part Number
- PS563-AB-0254-S
- Manufacturer
- Parlex Corp.
- Product Category
- Rectangular Cable Assemblies
- Brief Description
- CABLE ASSY 31POS RCPT-RCPT 10"
- Datasheet Download
- PS563-AB-0254-S.pdf
Availability of PS563-AB-0254-S
Available Quantity
5265 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 15.96000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PS563-AB-0254-S, we specialize in Parlex Corp. all series electronic components. PS563-AB-0254-S can be shipped within 24 hours after order. If you have any demands for PS563-AB-0254-S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PS563-AB-0254-S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PS563-AB-0254-S
| Internal Part Number | EIS-PS563-AB-0254-S | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | DF9 Display Cables | |
| Standard Package | 30 | |
| Category | Cable Assemblies | |
| Family | Rectangular Cable Assemblies | |
| Series | PS-563 | |
| Connector Type | Socket to Socket | |
| Number of Positions | 31 | |
| Number of Rows | 2 | |
| Pitch - Connector | 0.039" (1.00mm) | |
| Pitch - Cable | - | |
| Length | 0.833' (254.00mm, 10.00") | |
| Features | - | |
| Color | Gray, Ribbon | |
| Shielding | Unshielded | |
| Usage | Display Cable | |
| Cable Termination | IDC | |
| Contact Finish | - | |
| Contact Finish Thickness | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PS563-AB-0254-S | |
| Related Links | PS563-A, PS563-AB-0254-S Datasheet, Parlex Corp. Distributor | |
PS563-AB-0254-S Details Description
