CEL (California Eastern Laboratories) PS8502L1-V-AX
- Mfg. Part Number
- PS8502L1-V-AX
- Manufacturer
- CEL (California Eastern Laboratories)
- Product Category
- Optoisolators - Transistor, Photovoltaic Output
- Brief Description
- OPTOISOLATOR 5KV TRANS 8DIP
- Datasheet Download
- PS8502L1-V-AX.pdf
Availability of PS8502L1-V-AX
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.68000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PS8502L1-V-AX, we specialize in CEL (California Eastern Laboratories) all series electronic components. PS8502L1-V-AX can be shipped within 24 hours after order. If you have any demands for PS8502L1-V-AX, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PS8502L1-V-AX Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PS8502L1-V-AX
| Internal Part Number | EIS-PS8502L1-V-AX | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Isolators | |
| Family | Optoisolators - Transistor, Photovoltaic Output | |
| Series | NEPOC | |
| Packaging | Tube | |
| Number of Channels | 1 | |
| Voltage - Isolation | 5000Vrms | |
| Current Transfer Ratio (Min) | 15% @ 16mA | |
| Current Transfer Ratio (Max) | - | |
| Turn On / Turn Off Time (Typ) | 220ns, 350ns | |
| Rise / Fall Time (Typ) | - | |
| Input Type | DC | |
| Output Type | Transistor | |
| Voltage - Output (Max) | 35V | |
| Current - Output / Channel | 8mA | |
| Voltage - Forward (Vf) (Typ) | 1.7V | |
| Current - DC Forward (If) (Max) | 25mA | |
| Vce Saturation (Max) | - | |
| Operating Temperature | -55°C ~ 100°C | |
| Mounting Type | Through Hole | |
| Package / Case | 8-DIP (0.400", 10.16mm) | |
| Supplier Device Package | 8-DIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PS8502L1-V-AX | |
| Related Links | PS8502, PS8502L1-V-AX Datasheet, CEL (California Eastern Laboratories) Distributor | |
PS8502L1-V-AX Details Description
