Phihong USA PSAA30R-560-R-CN5
- Mfg. Part Number
- PSAA30R-560-R-CN5
- Manufacturer
- Phihong USA
- Product Category
- AC DC Desktop, Wall Adapters
- Brief Description
- AC/DC WALL MOUNT ADAPTER 56V 30W
- Datasheet Download
- PSAA30R-560-R-CN5.pdf
Availability of PSAA30R-560-R-CN5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 34.47000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PSAA30R-560-R-CN5, we specialize in Phihong USA all series electronic components. PSAA30R-560-R-CN5 can be shipped within 24 hours after order. If you have any demands for PSAA30R-560-R-CN5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PSAA30R-560-R-CN5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PSAA30R-560-R-CN5
| Internal Part Number | EIS-PSAA30R-560-R-CN5 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Desktop, Wall Adapters | |
| Series | PSAA30R | |
| Region Utilized | International | |
| Form | Wall Mount | |
| Input Type | Multi-Blade (Sold Separately) | |
| Voltage - Input | 90 ~ 264 VAC | |
| Voltage - Output | 56V | |
| Current - Output (Max) | 540mA | |
| Power (Watts) | 30W | |
| No Load Power Consumption | 300mW (Max) | |
| Polarization | Negative Center | |
| Applications | ITE (Commercial) | |
| Efficiency | Level V | |
| Operating Temperature | 0°C ~ 40°C | |
| Output Connector | Barrel Plug, 0.7mm I.D. x 2.5mm O.D. x 10.0mm | |
| Size / Dimension | 3.26" L x 2.17" W x 1.54" H (82.7mm x 55.0mm x 39.1mm) | |
| Approvals | CE, cULus | |
| Power (Watts) - Max | 30W | |
| Input Connector | Multi-Blade | |
| Cord Length | 59" (1.50m) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PSAA30R-560-R-CN5 | |
| Related Links | PSAA30R-, PSAA30R-560-R-CN5 Datasheet, Phihong USA Distributor | |
