Parlex Corp. PSR1635-16
- Mfg. Part Number
- PSR1635-16
- Manufacturer
- Parlex Corp.
- Product Category
- Flat Flex Cables (FFC, FPC)
- Brief Description
- CABLE FLAT FLEX 16 COND .100"
- Datasheet Download
- PSR1635-16.pdf
Availability of PSR1635-16
Available Quantity
5049 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 540.00000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PSR1635-16, we specialize in Parlex Corp. all series electronic components. PSR1635-16 can be shipped within 24 hours after order. If you have any demands for PSR1635-16, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PSR1635-16 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PSR1635-16
| Internal Part Number | EIS-PSR1635-16 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Cables, Wires | |
| Family | Flat Flex Cables (FFC, FPC) | |
| Series | PSR1635 | |
| Number of Conductors | 16 | |
| Pitch | 0.100" (2.54mm) | |
| Cable Length | 500' (152.4m) | |
| Cable Width | 1.70" (43.18mm) | |
| Jacket (Insulation) Material | Polyester | |
| Jacket (Insulation) Thickness | 0.0020" (0.051mm) | |
| Conductor Material | Copper, Bare | |
| Conductor Plating | Tin | |
| Ratings | UL Style 2643 | |
| Features | Conductor 1 Tinned | |
| Current Rating | 3A | |
| Voltage Rating | 300V | |
| Operating Temperature | 105°C | |
| Wire Gauge | 27 AWG (Equivalent) | |
| Conductor Thickness | 0.003" (0.08mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PSR1635-16 | |
| Related Links | PSR16, PSR1635-16 Datasheet, Parlex Corp. Distributor | |
PSR1635-16 Details Description
