Sullins Connector Solutions PTC18DFAN
- Mfg. Part Number
- PTC18DFAN
- Manufacturer
- Sullins Connector Solutions
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- CONN HEADER .100 DUAL STR 36POS
- Datasheet Download
- PTC18DFAN.pdf
Availability of PTC18DFAN
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PTC18DFAN, we specialize in Sullins Connector Solutions all series electronic components. PTC18DFAN can be shipped within 24 hours after order. If you have any demands for PTC18DFAN, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PTC18DFAN Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PTC18DFAN
| Internal Part Number | EIS-PTC18DFAN | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | - | |
| Packaging | Bulk | |
| Contact Type | Male Pin | |
| Connector Type | Header, Unshrouded | |
| Number of Positions | 36 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.100" (2.54mm) | |
| Contact Mating Length | 0.318" (8.08mm) | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | - | |
| Contact Finish | Tin | |
| Contact Finish Thickness | 100µin (2.54µm) | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PTC18DFAN | |
| Related Links | PTC1, PTC18DFAN Datasheet, Sullins Connector Solutions Distributor | |
PTC18DFAN Details Description
