Texas Instruments PTH12000WAZT
.jpg)
- Mfg. Part Number
- PTH12000WAZT
- Manufacturer
- Texas Instruments
- Product Category
- DC DC Converters
- Brief Description
- MODULE PIP 12VIN 6A ADJ SMD
- Datasheet Download
- PTH12000WAZT.pdf
Availability of PTH12000WAZT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.13500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PTH12000WAZT, we specialize in Texas Instruments all series electronic components. PTH12000WAZT can be shipped within 24 hours after order. If you have any demands for PTH12000WAZT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PTH12000WAZT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PTH12000WAZT
| Internal Part Number | EIS-PTH12000WAZT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Manufacturer Product Page | PTH12000WAZT Specifications | |
| Standard Package | 250 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | PTH12000 | |
| Packaging | Tape & Reel (TR) | |
| Type | Non-Isolated PoL Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 10.8V | |
| Voltage - Input (Max) | 13.2V | |
| Voltage - Output 1 | 1.2 ~ 5.5 V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 6A | |
| Power (Watts) - Manufacture Series | - | |
| Voltage - Isolation | - | |
| Features | OCP, UVLO | |
| Mounting Type | Surface Mount | |
| Package / Case | 5-SMD Module | |
| Size / Dimension | 0.75" L x 0.50" W x 0.36" H (19.1mm x 12.7mm x 9.1mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 92% | |
| Power (Watts) - Max | 33W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PTH12000WAZT | |
| Related Links | PTH120, PTH12000WAZT Datasheet, Texas Instruments Distributor | |
