Texas Instruments PTH12050LAS
- Mfg. Part Number
- PTH12050LAS
- Manufacturer
- Texas Instruments
- Product Category
- DC DC Converters
- Brief Description
- MODULE PIP .8-1.8V 6A SMD
- Datasheet Download
- PTH12050LAS.pdf
Availability of PTH12050LAS
Available Quantity
5061 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 10.65286
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PTH12050LAS, we specialize in Texas Instruments all series electronic components. PTH12050LAS can be shipped within 24 hours after order. If you have any demands for PTH12050LAS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PTH12050LAS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PTH12050LAS
| Internal Part Number | EIS-PTH12050LAS | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Manufacturer Product Page | PTH12050LAS Specifications | |
| Standard Package | 56 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | PTH12050 | |
| Packaging | Tray | |
| Type | Non-Isolated PoL Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 10.8V | |
| Voltage - Input (Max) | 13.2V | |
| Voltage - Output 1 | 0.8 ~ 1.8 V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 6A | |
| Power (Watts) - Manufacture Series | - | |
| Voltage - Isolation | - | |
| Features | Remote On/Off, OCP, UVLO | |
| Mounting Type | Surface Mount | |
| Package / Case | 6-SMD Module | |
| Size / Dimension | 0.87" L x 0.50" W x 0.36" H (22.1mm x 12.7mm x 9.1mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 88% | |
| Power (Watts) - Max | 11W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PTH12050LAS | |
| Related Links | PTH12, PTH12050LAS Datasheet, Texas Instruments Distributor | |
PTH12050LAS Details Description
