Panduit PV18-10F-M
- Mfg. Part Number
- PV18-10F-M
- Manufacturer
- Panduit
- Product Category
- Terminals - Spade Connectors
- Brief Description
- TERM FORK VYL 22-18AWG #10
- Datasheet Download
- PV18-10F-M.pdf
Availability of PV18-10F-M
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PV18-10F-M, we specialize in Panduit all series electronic components. PV18-10F-M can be shipped within 24 hours after order. If you have any demands for PV18-10F-M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PV18-10F-M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PV18-10F-M
| Internal Part Number | EIS-PV18-10F-M | |
| Lead Free Status / RoHS Status | ||
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Connectors, Interconnects | |
| Family | Terminals - Spade Connectors | |
| Series | Pan-Term® | |
| Packaging | Bulk | |
| Terminal Type | Standard | |
| Stud/Tab Size | 10 Stud | |
| Width - Outer Edges | 0.350" (8.89mm) | |
| Length - Overall | 0.930" (23.62mm) | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Crimp | |
| Wire Gauge | 18-22 AWG | |
| Insulation | Insulated | |
| Features | Brazed Seam | |
| Color | Red | |
| Contact Finish | Tin | |
| Contact Material | Copper | |
| Insulation Diameter | 0.150" (3.81mm) | |
| Material - Insulation | Vinyl | |
| Length - Ring Center to Termination | - | |
| Length - Termination | - | |
| Tongue Inside Opening | 0.200" (5.08mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PV18-10F-M | |
| Related Links | PV18-, PV18-10F-M Datasheet, Panduit Distributor | |
PV18-10F-M Details Description
