Murata Electronics North America PVZ3A203A01R00
- Mfg. Part Number
- PVZ3A203A01R00
- Manufacturer
- Murata Electronics North America
- Product Category
- Trimmer Potentiometers
- Brief Description
- TRIMMER 20K OHM 0.1W SMD
- Datasheet Download
- PVZ3A203A01R00.pdf
Availability of PVZ3A203A01R00
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PVZ3A203A01R00, we specialize in Murata Electronics North America all series electronic components. PVZ3A203A01R00 can be shipped within 24 hours after order. If you have any demands for PVZ3A203A01R00, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PVZ3A203A01R00 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PVZ3A203A01R00
| Internal Part Number | EIS-PVZ3A203A01R00 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 5 | |
| Category | Potentiometers, Variable Resistors | |
| Family | Trimmer Potentiometers | |
| Series | PVZ3 | |
| Packaging | Cut Tape (CT) | |
| Resistance (Ohms) | 20k | |
| Power (Watts) | 0.1W, 1/10W | |
| Tolerance | ±30% | |
| Temperature Coefficient | ±500ppm/°C | |
| Number of Turns | Single | |
| Adjustment Type | Top Adjustment | |
| Resistive Material | Carbon | |
| Mounting Type | Surface Mount | |
| Termination Style | J Lead | |
| Size / Dimension | Square - 0.126" x 0.122" Face x 0.073" H (3.20mm x 3.10mm x 1.85mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PVZ3A203A01R00 | |
| Related Links | PVZ3A20, PVZ3A203A01R00 Datasheet, Murata Electronics North America Distributor | |
PVZ3A203A01R00 Details Description
